The Nokia 5110 is a basic graphic LCD screen for lots of applications. It was originally intended for cell phone screen. This one is mounted on an easy to solder PCB. It uses the PCD8544 controller, which is the same used in the Nokia 3310 LCD. The PCD8544 is a low power CMOS LCD controller/driver, designed to drive a graphic display of 48 rows and 84 columns. All necessary functions for the display are provided in a single chip, including on-chip generation of LCD supply and bias voltages, resulting in a minimum of external components and low power consumption. The PCD8544 interfaces to microcontrollers through a serial bus interface. Technical Specifications Dimensions: 42.75 mm (L)x 45.20 mm (W) x 5.00mm (H) Interface Type: SPI Pinouts: RST, CE, D/C, DIN, CLK, VCC, BL, GND Operating Voltage: 2.7V to 3.3V Documents Datasheet Arduino Example HookupGuide Example Code Bitmap Converter GitHub Important Note Make sure you are correctly setting the contrast value of the LCD (by writing to command register ) or you will be able to see very dim or nothing at all on the LCD. Package Includes 1x Nokia 5110 84×48 pixel LCD

The Nokia 5110 is a basic graphic LCD screen for lots of applications. It was originally intended for cell phone screen. This one is mounted on an easy to solder PCB. It uses the PCD8544 controller, which is the same used in the Nokia 3310 LCD. The PCD8544 is a low power CMOS LCD controller/driver, designed to drive a graphic display of 48 rows and 84 columns. All necessary functions for the display are provided in a single chip, including on-chip generation of LCD supply and bias voltages, resulting in a minimum of external components and low power consumption. The PCD8544 interfaces to microcontrollers through a serial bus interface. Technical Specifications Dimensions: 42.75 mm (L)x 45.20 mm (W) x 5.00mm (H) Interface Type: SPI Pinouts: RST, CE, D/C, DIN, CLK, VCC, BL, GND Operating Voltage: 2.7V to 3.3V Documents Datasheet Arduino Example HookupGuide Example Code Bitmap Converter GitHub Important Note Make sure you are correctly setting the contrast value of the LCD (by writing to command register ) or you will be able to see very dim or nothing at all on the LCD. Package Includes 1x Nokia 5110 84×48 pixel LCD
