RJ45 Female Connector with Transformer and LEDs
No Reviews Yet...

Product Details:

Place of Origin Guangdong, China (Mainland) Part Number B50(27-39)F4-42A-A223-B52
Brand Name B-TOP Type RJ45
Application PCB Gender Female
Port 1x1 LED Green/Yellow

Detailed Product Description:

1X1 female RJ45 connector with 10/100base transformer, with EMI finger and LEDs

Meet or exceeds IEEE802.3 standard

Main use:

  • Network Equipment: Modem, Hub, Switch, Router, Gateway, Firewall, Repeater, Bridge…
  • PC motherboard
  • Notebook

Spectifications:

Electrical   Mechanical
Current rating: 1 - 1.5A Insertion force: 2 contacts---350g
Voltage rating: 120 - 150V AC   4 contacts---500g
Insulation resistance: 500MΩ Min   6 contacts---750g
Withstand voltage: AC 1500Vrms 50Hz or 60Hz 1 Min   8 contacts---900g
Contact resistance: 20mΩ Max   10 contacts---1050g
PoE rating: 15W, 350mA, 84V (For PoE product only) Retention strength: 7.7Kg between jack and plug
    Durability: 750 mating cycles mini
Material
Housing: 1) glass filled PA66(ul 94v-0)
  2) glass filled PA46(ul 94v-0)
  3) glass filled PBT(ul 94v-0)
Spring wire: 1) 0.45mm dia phosphor bronze gold plating over nickel
  2) 0.35mm thickness phosphor bronze alloy
  selective gold plating over nickel
Shielding: 0.2mm thickness copper alloy with tin plated
Gold plating: 3μ″,6μ″,15,μ″,30μ″,50μ″
Working temperature: -20℃-70℃, -40℃-85℃
Relative humidity: 70%±10% RH

Electrical Specifications at 25℃

Insertion
Loss
dB max		 Return Loss dB min Crosstalk(dB TYP) Common Mode Rejection
(dB TYP)		 Hipot(Vrms)
1-100MHz 1-30MHz 30-60MHz 60-80MHz 1-30MHz 30-60MHz 60-80MHz 1-50MHz 50-150MHz
-1.0 -18 -16 -12 -40 -35 -30 -30 -
