20x4 LCD Display WhitE/Blue LED Backlight
A 20 x 4 character LCD display with white text on a vivid blue backlit LCD. The pictures don't do justice to the bright blue background with clear white text of this display.
4 lines of 20 characters.
Dimensions
- Width 3.9 inches (98mm)
- Height 2.35 inches (60mm)
- Display view size 76mm x 26mm
Pinout Connections
| Pin No | Symbol | Level | Description |
| 1 | VSS | 0V | Ground |
| 2 | VDD | 5V | Supply Voltage for logic |
| 3 | VO | (Variable) | Operating voltage for LCD |
| 4 | RS | H/L | H: DATA, L: Instruction code |
| 5 | R/W | H/L | H: Read(MPU?Module) L: Write(MPU?Module) |
| 6 | E | H,H->L | Chip enable signal |
| 7 | DB0 | H/L | Data bus line |
| 8 | DB1 | H/L | Data bus line |
| 9 | DB2 | H/L | Data bus line |
| 10 | DB3 | H/L | Data bus line |
| 11 | DB4 | H/L | Data bus line |
| 12 | DB5 | H/L | Data bus line |
| 13 | DB6 | H/L | Data bus line |
| 14 | DB7 | H/L | Data bus line |
| 15 | A | 5V | LED + |
| 16 | K | 0V | LED- |
