The STM32F103C8T6 is a development board for the ARM Cortex-M3 processor, designed to provide a low-cost platform that can still meet the requirements of many developers.

The STMF103xx medium-density performance line family incorporates the high-performance ARM Cortex-M3 32-bit RISC core operating at a 72 MHz frequency, high-speed embedded memories and an extensive range of enhanced I/Os and peripherals connected to two APB buses. These board’s features make it ideal for a wide range of applications such as motor control, power management, medical and handheld equipment, PC and gaming peripherals, GPS platforms, industrial applications and more.

Specifications

• On-board STM32F103C8T6 chip
• JTAG port and reset button
• 32.768 KHz and 8 MHz oscillator
• 5V to 3.3V chip AMS1117-3.3
• UART serial interface
• All I/O ports are marked
• On-board mini USB port
• Board Size: 52.1 x 35.5 mm
